Midmark Ritter M9 Sterilizer Parts
|
SPECIFICATIONS
|
| Media: Steam |
| Chamber Dimensions: 9" Dia x 15" Dept (22.8cm x 38.1cm) |
|
Overall Dimensions: 15" wide x 18.1" Dept x 16.4" Height
|
| Overall Dimensions: 38.1cm x 47.8cm x 41.8cm |
| Water Reservoir Capacity: 7/8 gal (3.31 Liters) |
| Weight: 70lbs (32 Kg) |
| For more information: Click here |
|
PARTS LIST
|
| Bellows Assembly |
RCB089 |
| Condensing Coil (Inside Tank) |
052-0173-00 |
|
Control Board
|
002-0434-03
|
| Control PC Board |
002-0369-02 |
| Dam Gasket |
AMLIG035FA |
| Door Gasket |
AMLIG027FA |
| Door Handle |
053-0912-00 |
| Display PC Board |
002-0434-03 |
| Hose Clips |
053-0388-01 |
| Male Elbow |
014-0184-01 |
| Pop Rivet |
042-0010-21 |
| Pressure Relief Valve |
002-0359-00 |
| Solenoid, Fill 120V |
002-0365-00 |
| Solenoid, Fill, 230V |
002-0365-01 |
| Solenoid, Vent 120V |
002-0366-00 |
| Solenoid, Vent 230V |
002-0366-01 |
| Temperature Sensor |
002-0357-00 |
|
